XCF/KYF flotation unit is composed of XCF flotation machine and KYF type flotation machine is composed of XCF as a slurry suction tank and KYF as a direct flow tank used in flotation operations. This kind of combined flotation machine can be configured horizontally, reducing infrastructure investment; eliminating the investment in lift pumps, reducing equipment investment in the mineral processing plant, and getting rid of the problem of high power consumption of the pump. So in what environment is this flotation unit suitable to operate?

1. Suitable for selection operations involving multiple returns

The characteristics of the selection operations in flotation plants are: The operation frequency is high, the foam quality is high, the concentration of the agent is high, the foam is sticky and not brittle. For example, the flotation and beneficiation operations of fluorite ore generally take 5 to 8 times, and the flotation and beneficiation operations of graphite ore generally take 8 to 10 times. In this kind of beneficiation process where there is a lot of medium ore return and a lot of operations, using the XCF/KYF flotation unit can not only keep the height of the flotation machines level, but also make the heights of all flotation machines the same, which greatly reduces the cost of infrastructure construction. difficulty, eliminating the configuration of the foam pump, eliminating problems such as insufficient foam pump lifting capacity due to the high viscosity and unbreakability of the concentrate foam, greatly simplifying the equipment configuration, and creating a simple and clear plant dressing environment .

2. Suitable for flotation operations with limited space

General mineral processing plants have strict height restrictions or old buildings The system transformation plant is suitable for XCF/KYF flotation unit. Due to the ladder configuration, the flotation machines of each operation (even each flotation machine) are at different heights, which brings inconvenience to the foundation construction of the factory building and the installation of foam pipelines. Especially when the old system is renovated and upgraded, the old factory building is limited by the lifting height of the crane and cannot achieve ladder configuration. In this case, the XCF/KYF flotation unit is used to put all the flotation machines at the same level, which not only saves installation space and cost, but also maximizes the advantages of horizontal configuration.

The above are the several application environments suitable for XCF/KYF flotation unit. If your mineral processing is in the above several environments In this case, you can choose the XCF/KYF flotation unit, but you need to conduct a mineral processing test. According to the test results, you can customize the appropriate XCF/KYF flotation machine model according to the suitable flotation process and the size of the processing plant.
