What are the innovations of Xinhai SF flotation machine?

Detailed design, the "speed booster" of the flotation machine

In order to efficiently complete the flotation operation and achieve energy saving and reduction In order to reduce consumption, Xinhai Mining has made many designs for the flotation machine in detail.

1. Increase the gap between the flotation machine impeller and the cover plate, so that the friction between the impeller, cover plate and other components will reduce the impact on the air suction volume of the flotation machine, which not only improves The suction volume is reduced, thereby reducing energy consumption and noise, achieving the purpose of stable production.

2. The forward-inclined tank design basically eliminates the dead spots in the flotation machine tank, speeds up the movement of foam, and effectively improves the flotation efficiency.

3. The backward-inclined double-sided blade impeller design can realize double circulation in the slurry. During the actual working process, while the impeller rotates, the slurry in the upper and lower impeller cavities is thrown out by centrifugal force, causing negative pressure to form in the upper and lower impeller cavities, thereby achieving the purpose of flotation and separation.

4. Similarly, the design of the backward-inclined double-sided blade impeller makes the slurry thrown out of the lower impeller cavity denser than the three-phase mixture thrown out by the upper blade, so the centrifugal force is greater, which eases the movement. The speed weakening phenomenon creates additional driving force for the three-phase mixture thrown out by the upper blade, and also increases the centrifugal force of the upper impeller cavity, which increases the vacuum degree in the upper impeller cavity and plays a good assisting role.

5. The special process design allows the slurry in the tank to circulate up and down in a fixed manner. This design is conducive to mineral suspension.

Demand configuration to improve user requirements

1. The impeller of the sf flotation machine can play two roles. One is to inhale sufficient air to mix with the slurry, and the other is to inhale sufficient air to mix with the slurry; One is to stir the slurry to fully mix it with the agent, and at the same time, refine the foam. The foam in the flotation cell will adhere to the bubbles, and as the bubbles float to the surface of the slurry, mineralized foam will be formed.

2. The gate height of the flotation machine is adjustable, making it more convenient and flexible to control the liquid level, so that useful foam can be hung out by the scraper to improve the sorting operation.

3. The rubber lining in the flotation machine tank can be selected according to user needs. The anti-corrosion and wear-resistant effect is more than twice that of other materials, which can effectively extend the life of the flotation machine.

4. Horizontal configuration can be achieved, which eliminates the need for a foam pump and reduces investment costs.

Xin As a mining machinery and equipment manufacturing enterprise, Haikou Mining Equipment has been committed to providing customers with practical flotation machine equipment and supporting processes. The new SF flotation machine developed by the company guarantees both detailed design and user experience. The equipment operates with high efficiency, high productivity and low consumption. In practical applications, Xinhai sf flotation machine has also received unanimous praise from customers.
