Click to add WeChatIn daily operation, the flotation machine works 24 hours a day. In the long run, if the working condition is not good or used improperly, it will cause wear or other malfunctions to the equipment itself, affecting the flotation efficiency. At the same time, it will also Increase the investment cost of mineral processing plant. Therefore, when the flotation machine is operating, routine maintenance and regular inspections should be carried out. So what are the requirements for daily maintenance and periodic inspection of flotation machines? Let’s find out together below.
On-the-job personnel are required to understand the structural performance of the flotation machine equipment and the functions of each component. , specifications and names, etc., and be familiar with the condition of the equipment to facilitate the implementation of maintenance and inspection procedures.
Inspection contents:
1. Check whether the bolts between various parts are loose or abnormal, the tension of the V-belt, whether the belt safety cover is complete and firm, Check whether the scraper parts are in good condition. If problems are found, on-duty personnel must deal with them promptly.
2. Check whether the motor is overheated, whether the motor bearing temperature exceeds the standard value, and whether the temperature of the scraper bearing exceeds 25°C.
3. Check the gap between the stator and rotor of the flotation machine, and whether there are any abnormalities in the main bearing, transmission belt and rotor fixing parts.
4. Check the impeller of the flotation machine. When the wear diameter of the impeller exceeds 10%, or there are holes or cracks, it needs to be replaced in time.
5. Check whether the scraping rate of the scraping mechanism has decreased. When the scraping mechanism vibrates or swings, check in time whether there are cracks in the transmission bearing and whether the couplings are detached.
6. Check the suction volume of the flotation machine.
7. Check the condition of each lubrication point and confirm whether there is sufficient lubricating oil at each lubrication point.
8. Check whether the ore discharge valve and the box body are straight, and whether the tank body is leaking ore.
9. Check the blower's inlet and exhaust pressure, bearing temperature and motor current changes, and observe the vibration and noise of the blower.
The daily cleaning of the flotation machine determines the working capacity, working period and One of the main measures to keep all major components working properly.
1. The equipment must be kept clean and hygienic, the operating room or machine room must be free of dust, and parts, materials, and tools must be stored neatly. Oil leaks everywhere
Clean up promptly.
2. Cleaning must be carried out in shifts and once a week.
3. Each platform must be cleaned promptly and there must be no accumulation of dust.
Lubrication management is an important part of flotation machine equipment, correct and reasonable , Timely lubrication of the flotation machine can reduce the wear and tear of the flotation machine and reduce the occurrence of failures. It is a prerequisite for ensuring the normal performance of the equipment. It can not only increase the utilization rate of the equipment but also improve the comprehensive benefits of the enterprise.
Inspection content:
1. During operation, pay attention to checking the motor and flotation machine, If the temperature of the bearings such as the fan is checked, add oil to each lubrication point regularly.
2. Regularly add grease to the scraper bearings and bushings.
3. Check the oil level of the fan every day. If necessary, stop the fan to add oil. The fan lubricating oil is 220# gear oil.
Lubrication requirements:
1. The brand of lubricating oil must comply with regulations. When using substitute oil, its performance should not be lower than the technical performance of the specified grease. It is subject to approval by the competent authorities.
2. Grease must be kept clean, use a special container to store the oil, and store it in a cool and sealed place. The temperature of the storage location must not exceed the specified storage temperature of lubricating oil.
3. Before filling the circumferential bearing with oil, the oil nozzle must be cleaned to avoid clogging of the oil filling hole. If it is clogged, it should be dealt with immediately. If it cannot be dealt with, it must be reported in time.
4. Each lubrication point should be replaced with oil as required. The stirring and scraping parts should be replaced with oil every three months; the main bearing is required to be filled with oil once a month.
5. The lubrication device must be complete.
6. When the fan operates continuously for 1,000 hours, the lubricating oil must be replaced once.
Preparation operations before maintenance
1. Before maintenance, inspection and inspection are required Identify equipment issues and develop plans accordingly.
2. Arrange spare parts, materials and personnel according to the maintenance plan.
3. Post employees need to clean the environment around the equipment and flush out the slurry in and around the tank.
Maintenance cycle and scope
| Maintenance cycle (months) | Maintenance content | |
| Minor repairs | 1 to 3 | 1. Check the wear of the impeller and cover plate; 2. Replace the scraper shaft and bearing seat; 3. Replace the scraper and scraper shaft; 4. Change the oil in the motor bearings . |
| Intermediate repair | 12 | 1. Replace the vertical shaft bearing; 2 , Replace the shaft bracket; 3. Replace the impeller cover. |
| Overhaul | 60 to 120 | 1. Replace the foam tank and repair the flotation tank; < br/>2. Replace pipeline gates, etc. |
Semi-annual maintenance plan
1. The float needs to be inspected every 6 months by operators and fitters. Select the machine to check all bearings to confirm whether the bearings are intact and the sealing performance is good, and change the oil once.
2. Every 6 months, employees at the post are required to check and record the wear and tear of the impeller and stator.
3. Check the belt tightness and pulley wear every 6 months.
4. Check each pipeline and gate every 6 months to see if there is any leakage, and whether the tank body and various components are in good condition.
5. Check the electrical circuits every 6 months, and organize and clean the electrical circuits to ensure that there is no leakage and that the electrical appliances are sensitive and reliable.
In order to ensure that the flotation machine can operate normally in the processing plant and maintain the normal working efficiency of the flotation machine, daily maintenance and regular inspections are essential. And need to be equipped with professional maintenance personnel to carry out the work.
Learn more about flotation machine maintenance knowledge and consult Xinhai Mining. We can not only produce flotation machine equipment, but also provide mineral processing technology solutions and mineral processing plant construction. Xinhai Mining Equipment Co., Ltd. has a dedicated installation and commissioning team to provide training for the flotation machine maintenance and repair plan.
