200m³ The inflatable agitation flotation machine is a common large-scale flotation equipment in mineral processing plants. The tank of this type of flotation machine is cylindrical and the cross-section of the tank is circular (the pulp is dispersed Uniform), each groove is equipped with 2 circular foam grooves and 1 foam cone. The inner foam groove also has the function of pushing foam, shortening the foam transportation distance and accelerating foam recovery.

In addition, the high-speed backward-inclined impeller blades and damped straight-suspended stator design are more conducive to sorting and are conducive to increasing the coarse particles. and fine mineral recovery.

200m³The structural composition of the aerated agitated flotation machine

The structure of the 200m³ aerated agitated flotation machine is mainly composed of ore discharge Valve, tank body, stator, foam tank, motor, bearing body, spindle, air distributor, impeller, etc.

200m³Performance Parameters of Inflated Stirring Flotation Machine

Tank size7.5m×6.5m

Installed power220kW

Inflation volume0.6~ 1.8m³/(m²·min)

Processing capacity40～100m³/min

200m³Advantages and Features of Inflatable Stirring Flotation Machine

This large inflatable agitated flotation machine operates smoothly, with stable foam layer and no Turning phenomenon; strong stirring force, stable slurry flow; uniform distribution of mineral particles in the tank, no stratification; no dead zone in the tank, no slurry deposition; the aeration amount can be adjusted arbitrarily according to the requirements of the ore properties, and the air is evenly dispersed, The dispersion is high, the bubble size distribution is reasonable, and the flotation dynamics performance meets the requirements of large flotation machines; the automatic liquid level control system can be adjusted as needed, and the control accuracy meets process requirements; the thickness of the foam layer can be adjusted as needed; at full load It can start normally after parking.

The above is an introduction to the structure, composition, advantages and features of the 200m³ inflatable stirring flotation machine. If you want to know more about flotation machine equipment, you can consult Xinhai.
