The 10 cubic gold ore flotation machine refers to a flotation machine with an effective volume of 10m3 and a processing capacity in the range of 4~15m3/min. There are many flotation machine models with 10 cubic meters requirements, specifically: Which ones? What's the price? Let’s analyze them one by one!

10 cubic flotation machine model types

The currently common 10 cubic gold ore flotation machine models include XCF, KYF, JJF, BF, BF flotation machines, etc.

XCF type 10 cubic flotation machine

The model is XCF-10, and the effective volume is 10m³, impeller diameter 720mm, processing capacity 4~10m³/min. This type of flotation machine inflates self-priming slurry and needs to be equipped with a blower to inflate it externally. It has strong stirring ability, uniform dispersion and less tailings deposition. It is suitable for fine particle roughing, sweeping and selection operations in the dressing plant.

KYF type 10 cubic flotation machine

The model is KYF-10, the effective volume is 10m³, and the impeller diameter is 630mm , with a processing capacity of 4.0~10 m³/min. It cannot self-prime slurry or air. It requires a blower and a lifting pump. It has large processing capacity and high mineral processing efficiency, and is suitable for large-scale mineral processing plants. Do rough selection and sweeping operations.

JJF type 10 cubic flotation machine

The model is JJF-10, the effective volume is 10m³, and the processing capacity is 5.0-10 m³/min. This flotation machine cannot absorb slurry but can self-aspirate. It has large air suction capacity, good dispersion effect, moderate stirring degree, and good ore particle suspension effect. It is used in mineral processing. The factory is suitable for rough selection and sweeping operations.

BF type 10 cubic flotation machine

The model is BF-10, the impeller diameter is 760mm, and the processing capacity is 5.0 ~10 m^{3/min, the flotation machine has Type I and Type II, which can self-prime slurry and self-prime. Each tank has the triple functions of slurry suction, air suction and flotation, and can be completed without any auxiliary equipment. Flotation operations are mostly suitable for coarse particle flotation in mineral processing plants.}

How much does a 10 cubic meter flotation machine cost?

As for how much a 10 cubic meter gold ore flotation machine costs, it depends on the actual processing volume of the user and the type of minerals processed. What are the characteristics? After all, there are many types and models of 10 cubic flotation machines, and the specific processing conditions are different. In addition, you also need to look at the selected flotation machine manufacturer, the selected materials, the selected accessory materials, the manufacturer’s qualification certification and personnel ratio, etc., because the flotation machine materials selected by each flotation machine manufacturer are not necessarily the same. , the selected accessory materials are not necessarily the same, and whether the flotation machine manufacturer has its own production qualifications, talent allocation, etc. will affect the pricing of the flotation machine.

If you want to know the specific price of the 10 cubic gold ore flotation machine, it is recommended to contact the manufacturer directly for consultation. For example, Xinhai Mining will handle it through confirmation Depending on the volume, type of ore processed and conditions of the concentrator, etc., we will customize a suitable 10 cubic flotation machine model for you and give you a suitable quotation.

Advantages and features of the 10 cubic flotation machine

It has moderate aeration and many bubbles, which can ensure faster flotation speed;

The stirring power of the flotation machine is large enough , can better ensure the fusion of mineral particles and water, and ensure the attachment of mineral particles to drugs and bubbles;

The large processing capacity can better adapt to higher processing volumes and ensure the attachment of mineral particles to drugs. , the bubbles are in full contact;

The structure is simple, the design is reasonable, and the maintenance and management are relatively convenient, which can better ensure long-term safe operation, discharge the foam concentrate in a timely and effective manner, and improve work efficiency.

The above is an introduction to the main models of 10 cubic gold ore flotation machines and the processing capacity and application characteristics of each model. As for the price of the flotation machine, the editor once again recommends contacting the manufacturer and directly asking for a quote for more details.
