Phosphorus resources are a non-renewable mineral resource that plays a vital role in global industrial and agricultural production. As an important component of fertilizers, chemical raw materials, feed and other fields, the supply of phosphate resources is related to the normal operation of many industries. However, since the formation of phosphate ore in nature is affected by many factors and is accompanied by a large amount of gangue mineral impurities, phosphate in its original state is not suitable as a direct raw material for industrial production. Therefore, after phosphate is mined, it must undergo a series of beneficiation treatments to remove impurities and increase the enrichment of phosphorus in order to meet industrial standards.

1. Phosphate deposit types

Worldwide, phosphate deposits can be divided into five main types, each of which has different formation conditions and mineral characteristics, which brings challenges to the design of beneficiation processes. Here are the five main types of phosphate deposits:

Weathered phosphate deposits:Formed by weathering, common in shallow surface layers.

Metamorphic phosphate deposits:Formed by geological metamorphism, the ore quality is usually high.

Marine sedimentary deposits:Deposited in the marine environment, it is the most common type of phosphate in the world.

Thermal phosphate deposits:Formed by volcanic activity or magma cooling, with complex mineral types.

Biological phosphate deposits: Formed by biological action, usually distributed in special geological environments.

Currently, apatite deposits with economic value mainly come from metamorphic phosphate deposits and thermal phosphate deposits.

2. Phosphate ore dressing process

There are many types of phosphate ores, and their associated gangue minerals and impurities are different. Therefore, the selection of dressing process must be based on the characteristics of the ore type. According to the properties of its associated minerals, phosphate ores can be divided into the following three categories:

1. Siliceous phosphate phosphate ore dressing

The associated minerals of this type of phosphate ore are mainly chalcedony, quartz or silicon dioxide in the form of protein. Siliceous phosphate ore can effectively remove harmful impurities through gravity separation or flotation to achieve the purpose of phosphate enrichment. The gravity separation process utilizes the difference in mineral density, and the flotation process utilizes the physical and chemical properties of the mineral surface to separate apatite from gangue minerals through bubbles. The processing technology of this type of ore is relatively mature and the technical difficulty is relatively low.

2. Clay Phosphate Ore Beneficiation

The associated minerals of clay phosphate ore are mainly clay, alumina and hydrated iron. Because clay mineral particles are small and dispersed, scrubbing and washing processes are usually used to remove impurities. Scrubbing can separate clay minerals from apatite particles by water flow or mechanical action. Since these associated minerals are relatively easy to separate, the beneficiation of this type of phosphate ore is relatively simple and has a high beneficiation efficiency.

3. Beneficiation of carbonate phosphate ore

Carbonate phosphate ore is mainly composed of calcium phosphate or phosphate-containing limestone, sometimes mixed with a small amount of quartz. The beneficiation of this type of ore is relatively difficult, and there is currently no large-scale, mature beneficiation process that can successfully separate all carbonate phosphate ores. Since carbonate minerals and apatite have similar physical properties, it is difficult to effectively separate them using conventional physical beneficiation methods. Although the beneficiation of this type of ore is relatively difficult, its reserves account for 2/3 of the world's phosphate resources and are widely distributed. Therefore, with the increasing demand for raw materials in the phosphate industry, it is very necessary to rationally mine and sort low-grade sedimentary phosphate ores containing carbonate impurities in the future. This will not only ensure the continuous supply of phosphorus resources, but also improve the utilization rate of phosphate resources and promote the further development of beneficiation technology.

The above content is a brief overview of phosphate deposits and different types of phosphate ores and beneficiation technologies. Against the backdrop of increasing global demand for phosphate ores, the continuous advancement of beneficiation technology is particularly important. In order to improve the utilization rate of phosphate ores, future beneficiation processes must be more efficient, environmentally friendly, and adaptable to the complex properties of different types of phosphate ores. With the advancement of science and technology, new flotation agents, gravity separation equipment, and emerging beneficiation processes may bring breakthroughs in the treatment of carbonate phosphate ores. In addition, waste treatment and resource recovery during the beneficiation process will also become key research areas to ensure the sustainable utilization of mineral resources.
