Mechanical agitation flotation machine, self-priming air, can be adjusted according to the volume of minerals Measure the weight of a single tank equipped.

• [Processing capacity]:2～35m³/min

• [Effective volume]:4~28m³

• [Application environment]:XJQ type flotation machine is mostly suitable for roughing and sweeping operations of various metallic and non-metallic minerals in mineral processing plants.

Advantages and features of xjq type flotation for copper mines

XJQ flotation machine is of shallow groove type, with small impeller diameter and low speed. The power consumption is low, and the weight of a single tank can also be equipped according to the volume of minerals. Its impeller diameter, impeller speed, etc. will also change accordingly to improve flotation efficiency.

1. The gap between the impeller and the stator of the The amount is large, up to 2.5 times, which is beneficial to the mineralization of minerals, medicines and gas.

2. The stator of the Xjq flotation machine is umbrella-shaped and equipped with a perforated dispersion cover. It can separate the vortex generated by the impeller from the foam layer to ensure the stability of the slurry surface.

3. The mixing degree of the xjq flotation machine is moderate, the solid particles are suspended well, and they do not sink in the tank. There is no need to discharge the ore when the machine is stopped.

4. The impeller of the XJQ flotation machine is exposed under the stator, which makes the stirring and circulation of the slurry more efficient.

5. The suction volume is large, and the inflation volume per square meter per minute can be adjusted within the range of 0.1-1 cubic meters.

6. There is a false bottom above the tank bottom. The slurry can flow between the tank bottom and the false bottom and circulate through the diversion pipe. Therefore, the slurry can be circulated in the lower part along a fixed route, and the height of the impeller can also be increased, and the amount of aeration can be increased so that the bubbles can be fully dispersed.

Principle of xjq type flotation machine for copper mines

When the impeller of the XJQ type flotation machine rotates, eddy currents are generated in the vertical cylinder and diversion tube. This eddy current forms a negative pressure. The air is sucked in from the air inlet pipe and mixed with the slurry sucked in through the guide pipe in the impeller and stator areas. The mixed flow of pulp and gas is formed into tangential movement by the impeller, and then converted into radial movement by the action of the stator, and is evenly distributed in the flotation tank. The mineralized bubbles rise to the foam layer and are scraped out by the scraper to produce foam.

Model parameters of xjq flotation equipment for copper mines

If you want to know the specifications and models of Xinhai flotation machines or equipment quotations, you can consult Xinhai customer service or call the hotline: 15311826613.
